YC Hydraulic Piling Hammers
CFM hydraulic pile hammer is the result of the hydraulic hammer designing, using and manufacturing experience for more than ten years. It is with simple design and fine design, and the striking energy can be adjustable according to foundation condition and pile depth. Pile in the same foundation condition can be program group pile copied by the trailing pile.
Besides that, the cap can be designed according to the customer requirement, to be suitable for each kinds and specifications of concrete pile, steel tube pile and steel plate pile. CFM can supply each kinds of hydraulic pile hammer, from 60kJ to infinity. Simple reliable design, find manufacturing and fast service can make sure the pile hammer give full play.
Onshore and offshore hydraulic pile hammer uses combine ram technology (patent), and is easy for users to make reasonable choice for ram weight according to different foundation condition and piles. The users can get different type pile hammer through combining rams with different weight. Considering price and performance, this kind of pile hammer with combined ram technology is best economic choice. This also can prolong the striking action time, with big imputing energy and protect the prefabricated concrete pile head. The pressurize fully close hammer body technology(patent) and fully hydraulic driving technology can overcome the shortcomings of the traditional diesel oil pile hammer, such as noise, smoke, high energy consumption and ram lifting difficult for soft foundation and so on. This hammer can match with bumper to suit for city working. It is mainly for onshore foundation pile constructions, such as high building, seaport enlarging, water dam and transporting facilities and so on, especially for each kinds and specifications of prefabricated concrete piles, steel tube piles and steel plate piles.
The key technology and features:
Pressurize fully close hammer body (patent) make sure it can work with high reliability in very bad outside environment, especially the deep water working.
Combine ram technology (patent). It is easy for users to make reasonable choice for ram weight according to different foundation condition and piles. The users can get different type pile hammer through combining rams with different weight. This kind of pile hammer with combined ram technology is best economic choice.
Combine ram technology (patent) also can prolong the striking action time, with big imputing energy and protect the prefabricated concrete pile head.
High integrated hydraulic driving system can make sure it work with high efficiency, energy saving, environment friendly and high reliability.
Automatic close technology for high pressure pipeline if pressure losing, is to avoid oil leakage during unusual knocking.
Oil drain technology for pipeline can make sure the oil drain out when shifting to other place, to avoid oil leakage and pollution.
Modern program control technology can realize normal and automatic control for striking energy and frequency in the same foundation condition. The striking energy can be willfully preset in the rated range.
Fine sensor technology, remote technology and man-machine interface can automatic monitor the pressure, temperature, position and its condition, to realize pile hammer numerical control and malfunction automatic diagnosing and displaying.
It can be guiding pile or free lifting pile.
main technical parameter:
Structural parameters
05 series
10 series
20 series
20A
series
30
series
40
series
40A
series
type
unit
YC60
YC80
YC110
YC90
YC105
YC120
YC150
YC165
YC180
YC210
YC270
YC300
YC360
YC400
YC450
YC500
YC600
YC700
YC780
YC900
YC1000
Nominal energy
KJ
60～110
90～180
210～360
400～450
550～700
780～900
1000
Min. striking Stroke
mm
200
Max. striking Stroke
mm
1200
1500
1800
Ram weight
T
4～7
5～10
12～20
18～20
24～30
35～40
40
total weight without cap
T
7.5～10.5
12～17
26～34
33～35
45～51
63～68
70
Strike frequency
min-1
30～60
30～90
25～80
25～70
Working Pressure
MPa
11～21
21～28
25～28
Working flow
L/Min
190
240
500
750
1000
Main motor power
Kw
110
265
396
528
Cap weight
Kg
500～2000
Note: the cap can be designed and made according to the customer requirement. Reserve the right to change the parameters without prior notice.
